Professional Wireless (Karaoke) Microphone System

UW-500

UW-500 professional wireless microphone system receives channel parameters through IR with wide operational range up to 90m. Each wireless karaoke microphone has 100 selectable channels & volume controls. Contact us via email.

This wireless microphone system uses our latest technology, wireless karaoke microphone system UW-500 receives channel parameters through IR with wide operational range up to 90m. Each wireless karaoke microphone has 100 selectable channels and independent volume controls. This UHF system features 6-axis gyroscope to automatically enter mute mode when idling for 5~10 seconds. With three selectable distance adjustment switches to meet your demands, the UW-500 can be applied to comprehensive situations.

❖ COMPETITIVE ADVANTAGES

Distortion-Free Reproduction
Digital amplifier development is poised to become a mainstream and digital amplifier and speaker will be obtaining a distortion-free sound while communicating with digital wireless microphones.
Archiving the Perfect Sound
Digital wireless system allows full dynamic range without audible noise, as the audio signal is not compressed in the transmitter and expanded in the receiver. Since there are no commander circuits to muck up the sound, the sound from digital wireless would sound better than analog system.

❖ TECH SPECS

Product	Combo (1Receiver + 2 Transmitters)
Combo	UW-500R	UW-500M	UW-500B
Combo 1	1	1	1
Combo 2	2	2
Combo 3	1		2

Model	UW-500R UHF Wireless Receiver
Power Consumption	12w (Max)
Receiver Sensitivity	-95dbm
Mixing Output Socket	ø6.3mm Socket
Balanced Output Socket	XLR Socket
Dimension (mm)	419 × 164 × 53 mm
Weight	1500g

Model	UW-500M UHF Wireless Handheld Microphone
Carrier Frequency	Depends on Regional Frequency Band
Transmit Power	10dBm (±2dBm)
Microphone Capsule	Dynamic
Polar Pattern	Super-Cardioid
Impedance	600Ω
Frequency Response	80 ~ 12KHz
Current Consumption	120mA
Battery	Size AA x 2pcs
Operation Range	90 Meters (In Open Area)
Battery Life	Approximately 12 Hours (Uses Alkaline Batteries)
Dimension (mm)	ø52 × 258 mm
Weight (Without Batteries)	390g

Model	UW-500B UHF Wireless Bodypack
Carrier Frequency	Depends on Regional Frequency Band
Emissive Power	-10dBm (±2dBm)
Frequency Response	80Hz ~ 12KHz
Consumption Current	120mA
Battery	Size AA x 2pcs
Operation Range	90 Meters (In Open Areas)
Battery Life	Up to 12 Hours (Alkaline)
Dimension (mm)	170 × 65 × 31 mm
Weight	60g

❖ FREQUENCY RESPONSE

❖ MANAGEMENT SYSTEM CERTIFICATIONS

❖ AWARDS

❖ PATENTS

❖ ABOUT US

❖ DESIGN, PRODUCTION & FACILITIES

❖ PRODUCT REALIZATION

If you want to get more info please visit our website.
